Applications: Oil & Gas, Petrochemical Plants, Chemical Processing, Power Generation, Water & Wastewater Treatment, Pharmaceutical Manufacturing, Food & Beverage Processing, Pulp & Paper Industry, Cement Plants, Steel & Metal Processing, HVAC and Building Automation, Marine & Offshore, Mining & Minerals, Textile Industry, Semiconductor & Electronics Manufacturing, Industrial Automation and Process Control, Utilities and Energy Sector, Calibration Laboratories, Instrumentation Maintenance Services, Manufacturing Plants.
Loop Calibrator Fluke 705 is a cost-effective, repair, integrated solution for calibration and maintenance of milliamp loops. It features a large display and simple, push-button interface for ease of use. Plus, it offers the other capabilities you need most to calibrate mA loops including
| Model No | 705 |
|---|---|
| Measuring Parameters | Current, Voltage |
| Voltage | 0 V to 28 V |
| Resolution_1 | 1 mV |
| Current Measurement | 0 to 24mA |
| Resolution_2 | 0.001 mA |
| Current Sourcing | 0 mA to 20 mA or 4 mA to 20 mA |
| Accuracy | 0.02 % Rdg + 2 counts |
| Loop Power | While measuring mA, 24 V |
| Storage Temperature | -40 ºC to 60 ºC |
| Operating Temperature | -10 ºC to 55 ºC |
| Operating Humidity | 35% for 50 to 55°C, 45% for 40 to 50°C, 75% for 30 to 40°C, 95% for 10 to 30°C |
| Temperature coefficient | -10 ºC to 18 ºC, 28 ºC to 55 ºC, ±.005% of range per ºC |
| Safety | CSA C22.2 No. 1010.1:1992 |
| Shock & Vibration | per MIL-T-28800 for a Class 2 Instrument |
| EMC | EN50082-1:1992 and EN55022:1994 Class B |
| Maximum voltage | 30V |
| Battery | One 9V battery |
| Warranty | 3 Years Manufacturing Warranty |
| Calibration | Calibration certificate is provided alongwith the instrument. |
| Domain | Calibration Services, Construction Sites / Outdoor, Industries, Laboratories and industrial applications, Measurement and Control Technology |
| Dimension | 152 X 70 X 41 mm |
| Manufacturer | Fluke |
| Weight | 1 kg |
| Dimensions | Array |
| SKU / Model | S-0560 |
